High Clearance Medium Speed Wire EDM

The OL774565FM High Clearance Medium Speed Wire EDM is designed for machining taller workpieces and applications that require additional vertical clearance around the worktable.

Compared with standard-height medium speed Wire EDM machines, the OL774565FM High Clearance model provides more space for high workpieces, thick molds, special fixtures and components with larger vertical dimensions.

Taizhou Ouling CNC Equipment Co., Ltd. provides this model for mold shops, tooling manufacturers and precision machining companies that need both multi-cut EDM capability and increased workpiece height capacity.

Some EDM applications are limited not by X/Y size, but by workpiece height.

The OL774565FM High Clearance model is suitable for:

• Thick mold blocks
• Tall tooling components
• High-profile inserts
• Large fixtures
• Deep mold structures
• Workpieces requiring additional clamping height

The increased vertical working space gives operators more flexibility when setting up taller or more complex components.

High Clearance Working Space

The main advantage of the OL774565FM High Clearance model is the increased vertical machining space.

This helps accommodate:

• Taller workpieces
• Thick mold plates
• Special fixtures
• Elevated clamping setups
• Deep-profile components

For manufacturers handling a wider range of part heights, this provides more flexibility than a standard-height machine.

Medium Speed Multi-Cut Machining

The machine supports multiple cutting passes, allowing rough cutting followed by finishing cuts.

This helps improve:

• Surface quality
• Profile consistency
• Dimensional accuracy
• Finished part appearance

The combination of high clearance and multi-cut capability makes the machine suitable for both larger-height workpieces and precision finishing requirements.

Flexible Setup for Special Fixtures

Some parts require:

• Raised clamping
• Custom supports
• Multi-level fixtures
• Special positioning structures

The additional vertical clearance gives users more freedom when arranging these setups without being restricted by standard machine height.

Suitable for Hard Conductive Materials

The OL774565FM High Clearance can process electrically conductive materials such as:

• Tool steel
• Hardened steel
• Stainless steel
• Mold steel
• Carbon steel
• Copper
• Aluminum
• Carbide

Because Wire EDM removes material through electrical discharge, hardened materials can be processed without direct mechanical cutting force.

Low Mechanical Stress

The non-contact machining process helps reduce deformation on:

• Thin sections
• Precision inserts
• Hardened workpieces
• Tall components
• Complex profiles

This is especially useful when machining parts that are difficult to clamp with conventional cutting methods.

The OL774565FM High Clearance Medium Speed Wire EDM is suitable for:

Thick Mold Components

• Thick mold plates
• Deep inserts
• Mold blocks
• Tall tooling components

Special Fixture Applications

• Raised fixtures
• Custom clamping systems
• Multi-level workpiece setups

Precision Metal Parts

• Complex profiles
• Hardened components
• High-section parts
• Customized tooling

Industrial Tooling

• Stamping dies
• Mold inserts
• Precision fixtures
• Special-shaped components

This model is suitable for users who regularly encounter workpieces that are too tall for standard Wire EDM machines.

Its main advantages include:

• Increased vertical clearance
• Better suitability for thick and tall workpieces
• More flexible fixture arrangement
• Multiple-cut machining capability
• Suitable for hardened conductive materials
• Low mechanical cutting force
• Practical for mold and tooling workshops

A standard-height Wire EDM is sufficient for most conventional parts.

However, additional clearance becomes important when machining:

• Thick mold blocks
• Tall inserts
• High fixtures
• Deep tooling structures
• Large clamping setups

The OL774565FM High Clearance model is designed specifically for these applications, helping reduce setup limitations and improve workshop flexibility.
