Technical Parameters
|
Item |
Specification |
|
Model |
OL500CR |
|
Work Table Size |
440 × 730 mm |
|
X/Y Axis Travel |
350 × 500 mm |
|
U/V Axis Travel |
60 × 60 mm |
|
Z Axis Travel |
280 mm |
|
Max. Workpiece Thickness |
300 mm |
|
Max. Workpiece Weight |
300 kg |
|
Machine Weight |
1900 kg |
|
Machine Dimensions |
1600 × 1300 × 1750 mm |
|
Max. Taper Angle |
±6° / ±15° / ±30° / 80 mm |
|
Max. Machining Speed |
200 mm²/min |
|
Max. Wire Feeding Rate |
1~11.4 m/sec (Frequency Adjustable) |
|
Positioning Accuracy |
±0.01 mm |
|
Repeat Positioning Accuracy |
±0.004 mm |
|
Optimal Machining Accuracy |
±0.004 mm |
|
Surface Roughness |
Ra 1.0 μm |
|
Molybdenum Wire Diameter |
0.10~0.25 mm |
|
Power Supply |
3 Phase / 380V / 50Hz |
|
Power Consumption |
3 kVA |
Standard Configuration
| Axis linkage | XYUV axis simultaneous | |
| Guide rail type | Linear guideway | |
| XYUV axis drive | Stepper motor/servo motor | |
| Z axis drive | Hybrid motor | |
| Central lubrication system | Automatic | |
| Dielectric tank capacity | 110 L | |
| Controller | Vertical control cabinet | |
| Software platform | Window XP/Window 7 | |
| Control system | Auto-cut/ Win-cut/X8 | |
| Language display | Chinese/English/Russian | |
| Monitor | 17" LCD | |
| Digital readout display | XY axis DRO (5μm) | |
| CNC instruction | Standard ISO code | |
| Transmission type | USB/LAN | |
FAQ
Q: What Materials Can The OL500CR Process?
A: The machine can process conductive materials including stainless steel, tool steel, copper, aluminum, carbide, titanium alloy, and hardened metals.
Q: Does The Machine Support Taper Cutting?
A: Yes. The OL500CR supports taper cutting angles of ±6°, ±15°, and ±30° within 80mm thickness.
Q: Which Control Systems Are Available?
A: The machine supports Auto-cut, Win-cut, and X8 control systems.
Q: What Wire Diameter Is Compatible With The Machine?
A: The machine supports molybdenum wire diameters from 0.10mm to 0.25mm.
Q: Is Overseas Technical Support Available?
A: Yes. We provide installation guidance, technical support, operation training, and after-sales service for international customers.
